Explosion-proof ATEX Junction Box with 2 Blanking Plugs – for Explosion-proof LED High Bay

What is it?
You use this explosion-proof junction box to safely connect explosion-proof LED high bays to the mains or to link several fittings in areas where there is a risk of explosion, such as storage of flammable liquids, spray booths, chemical storage or dusty production areas. The box is supplied with 2 blanking plugs and 2 open cable entries; a cable gland is not included.

Fits
The junction box belongs to the explosion-proof LED high bays of 100W and 200W in our range. You will find the matching products, such as the fittings and the M25×1.5 cable gland, at the bottom of this page.

Installation and use
The box is fixed in place near the fitting. For every cable that enters the box you fit a cable gland in an open entry; unused openings are closed with the supplied blanking plugs. Always have the installation carried out by a qualified electrician who is familiar with working in ATEX zones.

How many do you need?
You need one junction box per connection or linking point. Because the box has 2 open cable entries, you need at most 2 cable glands per box: one for the incoming cable and one for the cable continuing to the next fitting.

Questions?
You will find the technical data of the matching fitting in the datasheet, which you can download on the product page of the fitting. Do you have a question about this product or are you unsure which version you need? Email us at info@dimay.com and we will be happy to help.
